Installation Instructions

The split foam and the tongue & groove hard plastic allows for easy installation around the hoses and cords.

Step 1. Connect the two critter guard sections together and center over the opening.

Step 2.* Drill six 9/64” holes evenly spaced, ¼” from the RV-Critter Guard edge.

Step 3. Screw the gray thumb latches into the holes drilled.

Step 4. Install foam seal around hose/cord in opening, foam should be flush with the top of the opening.

Step 5. Install the two RV-Critter Guard halves around the hose or cord and secure with thumb latches.

*On some models existing holes can be used if not counterbored too deep, remove screws that hold down the seal ring and install the larger thumb latches with screws supplied.

*On model #7’s it is necessary to drill holes.

Below shows installation using existing screw holes:
